Eco Duct 300 X 70 X 2 Metre Low Profile Ductwork
Description
300 x 70 x 2 METRE Low Profile Ductwork Eco Duct Green ( 9 pascals )
UL 181.11-2013 - AS/NZS 1530.3-1999
( ECO300FLAT2 )
Fastflex's 300 x 70mm Low Profile Eco Duct is the go-to solution for residential and light commercial ducted air conditioning installations where ceiling or wall cavity space is at a premium. The slim 70mm profile fits easily into tight spaces that standard round flexible duct simply won't accommodate, without sacrificing airflow performance.
Supplied in 2-metre lengths, this duct is manufactured to meet both the UL 181.11-2013 (USA) and AS/NZS 1530.3-1999 (Australian) standards for fire performance and material quality — giving installers and specifiers confidence in compliance on every job.
Key Features
- Low profile design — 300 x 70mm rectangular cross-section fits into ceiling cavities, wall chases and subfloor spaces where round duct won't go
- Green colour coding — easily identifies duct size and type on site, reducing installation errors on multi-duct runs
- 9 Pa static pressure rating — suitable for low-resistance supply air distribution in residential and light commercial ducted systems
- 2-metre lengths — easy to handle, transport and install; minimises offcuts and waste
- UL 181.11-2013 certified — meets USA standard for air ducts and air connectors for fire resistance and material performance
- AS/NZS 1530.3-1999 compliant — meets Australian and New Zealand standard for simultaneous determination of ignitability, flame propagation, heat release and smoke release
- Flexible construction — can be routed around obstacles and through tight spaces without rigid sheet metal fittings
Suitable For
Residential ducted split system supply air outlets, ceiling cavity installations with restricted height, wall cavity duct runs, subfloor air distribution, and any application where a low-profile rectangular duct is required in place of standard round flexible duct.
Trade note: Low profile duct has a higher resistance per metre than equivalent round flexible duct due to the rectangular cross-section and reduced hydraulic diameter. Always account for the 9 Pa rating when sizing runs — keep individual branch lengths short and avoid unnecessary bends to maintain system performance.
Specifications
| Duct Type | Low Profile Flexible (Eco Duct) |
| Dimensions | 300mm x 70mm |
| Length | 2 metres |
| Static Pressure Rating | 9 Pa |
| Colour | Green |
| Standard (AU/NZ) | AS/NZS 1530.3-1999 |
