Arth24Khta / Aoth24Kbta 7.1 Kw Fujitsu Ducted Complete Inc Uty-Rnrt Controller R32

SKU:
FUJDSTD7
Price:
$2,732.00 ex GST
Make an Enquiry

Description

ARTH24KHTA / AOTH24KBTA 7.1 KW
FUJITSU DUCTED COMPLETE INC UTY-RNRT CONTROLLER R32
1 PHASE HI STATIC STANDARD
7.1 KW COOL / 8.0 KW HEAT
500 L/SEC @ 210 PASC
1/4 - 1/2 PIPE SIZE
850 x 295 s/air trans
865 x 325 r/air trans
Pre Charged 20 metres / max 30 metre
indoor 1050 w x 500 d x 400 h 38 KGS
outdoor 820w x 716h x 320d 36 KGS
* RUN CURRENT 9.4 AMPS*
Flare Connection

Product Details

The Fujitsu ARTH24KHTA is part of Fujitsu's High Static Single Phase R32 ducted range — one of the most popular ducted systems in the Australian residential and light commercial market. This complete system includes the indoor unit, outdoor condenser and the UTY-RNRT backlit touch panel wall controller, ready for installation.

Up to 19.7% more energy efficient than previous Fujitsu ducted models, the R32 High Static range delivers powerful, quiet and reliable whole-home climate control. Rated for ambient operating temperatures up to 50°C in cooling mode, making it well suited to Australian conditions.

Cooling & Heating Performance The ARTH24KHTA delivers 7.1kW rated cooling (1.8–8.1kW variable) and 8.0kW rated heating (2.0–9.1kW variable). EER 3.32, COP 3.90. High static pressure design with 500 L/s airflow at 210 Pa — suitable for longer duct runs and multi-zone systems where standard static ducted units fall short.

Zone System Compatible Zone system compatible out of the box. Supports multiple zones for individual room temperature control. Connectable distributing duct for flexible duct layout. Fresh air intake capable for improved indoor air quality. Demand response enabled for energy management compliance.

Compact & Lightweight Indoor Unit The ARTH24KHTA features Fujitsu's latest compact indoor chassis — lighter and easier to handle on site than previous generations. Splittable design for installation flexibility in tight roof spaces. Supply air transfer opening 850 x 295mm, return air 865 x 325mm.

Includes UTY-RNRT Backlit Wall Controller The UTY-RNRT touch panel controller provides clear, easy-to-read backlit display and simple operation for homeowners. No separate controller purchase required — this is a complete ready-to-install system.

Key Features

  • Auto restart after power failure
  • Auto changeover between heating and cooling modes
  • Economy mode to limit maximum operating current
  • Blue fin outdoor heat exchanger for coastal corrosion resistance
  • Connectable distributing duct and fresh air duct
Specifications
  • Indoor unit: ARTH24KHTA
  • Outdoor unit: AOTH24KBTA
  • Controller: UTY-RNRT (included)
  • Refrigerant: R32
  • Power supply: 220–240V / 1 phase / 50Hz
  • Pipe size: 1/4" liquid x 1/2" gas (flare connection)
  • Pre-charge: 20m
  • Max pipe run: 30m
  • Max height difference: 25m
  • Running current: 9.4A cooling / 9.0A heating
  • Indoor dimensions: 1,050W x 500D x 400H mm, 38kg
  • Outdoor dimensions: 820W x 716H x 320D mm, 42kg
  • Supply air transfer: 850 x 295mm
  • Return air transfer: 865 x 325mm

Warranty 5 year manufacturer warranty.
